Brand: PVI

Model name: PM102ZY3

Screen size: 10.2

Screen type: LCD module, a-Si TFT-LCD

Resolution: 1024 (RGB) × 600 [WSVGA]

Pixel configuration: RGB vertical stripe

Display size: 222.72 × 130.5 mm (H × V)

Exterior dimensions: 235 × 145.8 × 6.5 mm (H × V × D)

Visual dimensions: 225.9 × 134.2 mm (H × V)

Surface treatment: matte finish

Brightness (cd/m ²): 350 (Typ.)

Contrast ratio: 600:1 (Typ.) [Transmission]

Best angle: 6 O'clock

Optical mode: TN, normally white display, transmissive

Viewing angle: 60/60/40/55 (Typ.) (CR ≥ 10)

Response speed: 15/25 (Typ.) (Tr/Td) ms

Color Quantity: 262K

Backlight type: 3S16P WLED, 30K hours, no driver

Screen weight: 314 ± 15g

Refresh rate: 60Hz

Touch function: None

Signal system: TTL (1 ch, 6-bit), FPC, 60 pins

Supply voltage: 3.3/3.3/9.1/17.0/-5.6V (Typ.) (VCC/VDD1/VDD2/VGG/VEE)

Maximum rating: Storage temperature: -30~80 ° C Operating temperature: -20~80 ° C
